Global event server. More...

#include <eventserver.h>

Public Member Functions
void	create_event (const std::string &event_id)
	Function to create a new event. More...

void	delete_event (const std::string &event_id)
	Function to delete an existing event. More...

void	set_event (const std::string &event_id)
	Function to activate an event. More...

void	reset_event (const std::string &event_id)
	Function to deactivate an event. More...

bool	event_is_set (const std::string &event_id)
	Function to query if the event is active or not. More...

int	get_num_events (void)
	function to get the number of event More...

int	get_num_activations (const std::string &event_id)
	Function to get the number of activations of a single event. More...

int	wait_first (std::list< std::string > events, int timeout=-1)
	Function to wait for the first event in a set. More...

void	wait_all (std::list< std::string > events, int timeout=-1)
	Function to wait for all the events is a set. More...

Static Public Member Functions
static CEventServer *	instance (void)
	Function to get a reference to the unique instance. More...

Protected Member Functions
	CEventServer ()
	Default constructor. More...

	CEventServer (const CEventServer &object)
	Copy constructor. More...

CEventServer &	operator= (const CEventServer &object)
	assign operator overloading More...

std::list< CEvent >::iterator	search_event (const std::string &event_id)
	Function to search for an specific event. More...

Detailed Description

This class implements an event server which is global to the application and also only one instance exist that is shared by all objects requiring events.

There is no limit in the number of events that can be created in the whole application. Each of this events is assigned a unique identifier at creation time which is provided by the user. All identifier must be different, an they are used afterwards to access the desired event.

By using an identifier to access the desired event, this class also isolates the low level details of the events implemented by the CEvent class by providing a public interface that allows access to alll event capabilities. Doing so, there is no direct access to the object outside the server.

The public interface allows to create and destroy events, signal and reset them, check its current state and also wait for a given set of them. Internally, it has a complete list of all event cretaed in the application so that any object or thread can use any event if its identifier is known.

This class also has a CMutex object to avoid race conditions or data corruption while several threads of execution are handling the same event in the server.

This class uses exceptions to report errors. The name of the exception class associated to this class is CEventServerException. For a more detailes descritpion, see the corresponding documentation.

Examples:: test_bothservers.cpp, and test_eventserver.cpp.

Definition at line 57 of file eventserver.h.

Constructor & Destructor Documentation

CEventServer::CEventServer ( )

protected

This constructor initializes the event list and the mutex object to access it. The list can only be modified through the public interface of the class.

The reference to the newly created object is not modified. This constructor is only called once and from inside the instance() function. It can not be called directly by the user since it is declared as protected.

Definition at line 28 of file eventserver.cpp.

Referenced by instance().

Here is the caller graph for this function:

CEventServer::CEventServer ( const CEventServer & object )

protected

This constructor is used to initialize a new object with the contents of an existing one. Since there could be only one instance of this class, only the pinstance attribute must be copied, but since it is static nothing is to be done in this constructor.

Parameters

object an existing instance of a CEventServer class which has been already initialized.

Definition at line 32 of file eventserver.cpp.

Member Function Documentation

CEventServer & CEventServer::operator= ( const CEventServer & object )

protected

This function overloads the assign operator for this class. Since there could be only one instance of this class, only the pinstance attribute must be copied, but since it is static, nothing is to be done.

Parameters

object an existing instance of a CEventServer class which has been already initialized.

Definition at line 36 of file eventserver.cpp.

std::list< CEvent >::iterator CEventServer::search_event ( const std::string & event_id )

protected

This function is used to search for a particular event inside the event handler list. It is protected because no one outside the class can have access to the particular CEvent objects.

If the required event exists, a reference to it is returned by the function, but if there is no event with the provided identifier, the function return a NULL reference, but does not throw any exception.

This function throws a CEventServerException in case of any error. See the corresponding documentation for a more detailed decription of this exception class.

Parameters

event_id A null terminated string that identifies the desired event. The necessary memory for this string must be allocated before calling this function.

Returns: A reference to the desired CEvent object, or a NULL reference if the event with the provided identifier does not belong to the event handler.

Definition at line 41 of file eventserver.cpp.

Referenced by create_event(), delete_event(), event_is_set(), get_num_activations(), reset_event(), set_event(), wait_all(), and wait_first().

Here is the caller graph for this function:

CEventServer * CEventServer::instance ( void )

static

This function returns a reference to the only instance of the singleton. When it is first called, a new object of this class is created, and the successive calls only return a reference to the previously created object.

Since this function is static, it can be call anywhere in the code so all objects can access the unique event handler.

Returns: A reference to the only instance of this class. This reference must not be freed until the application ends.

Examples:: test_bothservers.cpp, and test_eventserver.cpp.

Definition at line 64 of file eventserver.cpp.

References CEventServer().

Here is the call graph for this function:

void CEventServer::create_event ( const std::string & event_id )

This function creates a new event with a given identifier and adds it to the event handler. If there is an event in the internal list with the same identifier, the new event is not added and an exception is thrown. Otherwise, the new event is added to the list of events and can be accessed immediatelly by other threads using the provided identifier.

This function locks the access_events Mutex object to avoid other threads concurrently adding new events which could cause unpredictible errors. After calling this function, the only way to access the newly cretaed event is through its identifier, the user does not have any reference to the CEvent object inserted into the event list.

This function throws a CEventServerException in case of any error. See the corresponding documentation for a more detailed decription of this exception class.

Parameters

event_id a null terminated string with the event identifier. The identifier is stored internally in a different memeory location so that the parameter can be freed after calling this function. The identifier must not have any spaces or special characters, and must be unique.

Examples:: test_bothservers.cpp, and test_eventserver.cpp.

Definition at line 73 of file eventserver.cpp.

References CMutex::enter(), CMutex::exit(), and search_event().

Here is the call graph for this function:

void CEventServer::delete_event ( const std::string & event_id )

This function removes an existing event from the event handler. If the desired event is not in the internal list, an exception is thrown and nothing happens. Otherwise, the event is removed, and future reference to it will end with an exception thrown.

This function locks the access_events Mutex object to avoid other threads concurrently removing events which could cause unpredictable errors. This function throws an exception if there is any other error.

This function throws a CEventServerException in case of any error. See the corresponding documentation for a more detailed decription of this exception class.

Examples:: test_eventserver.cpp.

Definition at line 93 of file eventserver.cpp.

References CMutex::enter(), CMutex::exit(), and search_event().

Here is the call graph for this function:

void CEventServer::set_event ( const std::string & event_id )

This function provides access to the private CEvent objects through the public interface of the class. To see a more detailed description of its features, see the documentation on the set() function of the CEvent class.

This function throws a CEventServerException in case of any error. See the corresponding documentation for a more detailed decription of this exception class.

Parameters

event_id a null terminated string with the event identifier. The identifier is stored internally in a different memory location so that the parameter can be freed after calling this constructor. The identifier must not have any spaces or special characteres.

Examples:: test_bothservers.cpp, and test_eventserver.cpp.

Definition at line 111 of file eventserver.cpp.

References CMutex::enter(), CMutex::exit(), and search_event().

Here is the call graph for this function:

void CEventServer::reset_event ( const std::string & event_id )

This function provides access to the private CEvent objects through the public interface of the class. To see a more detailed description of its features, see the documentation on the reset() function of the CEvent class.

This function throws a CEventServerException in case of any error. See the corresponding documentation for a more detailed decription of this exception class.

Parameters

event_id a null terminated string with the event identifier. The identifier is stored internally in a different memory location so that the parameter can be freed after calling this constructor. The identifier must not have any spaces or special characteres.

Examples:: test_eventserver.cpp.

Definition at line 129 of file eventserver.cpp.

References CMutex::enter(), CMutex::exit(), and search_event().

Here is the call graph for this function:

bool CEventServer::event_is_set ( const std::string & event_id )

This function provides access to the private CEvent objects through the public interface of the class. To see a more detailed description of its features, see the documentation on the is_set() function of the CEvent class.

This function throws a CEventServerException in case of any error. See the corresponding documentation for a more detailed decription of this exception class.

Parameters

event_id a null terminated string with the event identifier. The identifier is stored internally in a different memory location so that the parameter can be freed after calling this constructor. The identifier must not have any spaces or special characteres.

Examples:: test_eventserver.cpp.

Definition at line 147 of file eventserver.cpp.

References CMutex::enter(), CMutex::exit(), and search_event().

Here is the call graph for this function:

int CEventServer::get_num_events ( void )

This functions returns the number of events currently in the internal event handler. This function locks the access_events Mutex object to avoid new events to be added or existing ones to be removed while accssing the number of elements in the internal list. This function throws an exception if there is any error.

Returns: An integer with the number of event sin the event handler. This value is always non-negative, but ther is no upper limit on the number of concurrent events.

Definition at line 165 of file eventserver.cpp.

References CMutex::enter(), and CMutex::exit().

Here is the call graph for this function:

int CEventServer::get_num_activations ( const std::string & event_id )

This function provides access to the private CEvent objects through the public interface of the class. To see a more detailed description of its features, see the documentation on the get_num_activations() function of the CEvent class.

Parameters

event_id a null terminated string with the event identifier. The identifier is stored internally in a different memory location so that the parameter can be freed after calling this constructor. The identifier must not have any spaces or special characteres.

Definition at line 176 of file eventserver.cpp.

References CMutex::enter(), CMutex::exit(), and search_event().

Here is the call graph for this function:

int CEventServer::wait_first	(	std::list< std::string >	events,
		int	timeout = `-1`
	)

This function waits on a set of events for the first one to became active. The events to be waited upon are referenced by its unique identifier and passed to the function through a list.

If all the event identifiers exist in the internal event handler, all their file descriptors are retieved and waited upon simultaneoulsy. If one or more of the identifiers do not exist, an exception is thrown.

If all the desired events exist, the function gets blocked until the first event is activated. Then, the active event is reset automatically and the position of the event in the event list is returned to inform the calling process which of the event has been activated.

If non of the event get active, the function is blocked forever. This function locks the access_events Mutex obejct except when it is actually waiting for the events, to allow other threads to activate the necessary events. Otherwise all the threads handling events will get blocked forever. This function throws an exception if there is any error.

This function throws a CEventServerException in case of any error. See the corresponding documentation for a more detailed decription of this exception class.

Parameters

events an STL list of constant references to event identifiers. This list must be created before calling this function, and several lists can be used with different sets of events in a single application. The number of events in this list is only limited by the number of events in the event handler. If one identifier appears sevaral times, only the first one is taken into account.

Returns: an integer with the position of the active event in the list of events to wait upon passed as an argument to the function. This value is always non-negative and its maximum value is the number of events - 1.

Parameters

timeout an integer value with the maximum ammount of time to wait for an event in miliseconds. If an event ocurrs before the specified time nothing happens, otherwise an exception is thrown. By default its value is -1 which indicates no timeout.

Examples:: test_bothservers.cpp, and test_eventserver.cpp.

Definition at line 194 of file eventserver.cpp.

References CMutex::enter(), CMutex::exit(), CTime::getTimeInTimeval(), search_event(), and CTime::set().

Here is the call graph for this function:

void CEventServer::wait_all	(	std::list< std::string >	events,
		int	timeout = `-1`
	)

This function is very similar to the wait_first() function, except that this one waits for all events in the list to became active. In this case there is no need to return any index value because the function will only finish when all the events are active.

The events that have been activated are actually removed from the list of event to wait upon, so that only the first activation of an event is actually handled by a call to this function. All the activated events are internally reset.

This function throws a CEventServerException in case of any error. See the corresponding documentation for a more detailed decription of this exception class.

Parameters

events	an STL list of constant references to event identifiers. This list must be created before calling this function, and several lists can be used with different sets of events in a single application. The number of events in this list is only limited by the number of events in the event handler. If one identifier appears sevaral times, only the first one is taken into account.
timeout	an integer value with the maximum ammount of time to wait for an event in miliseconds. If an event ocurrs before the specified time nothing happens, otherwise an exception is thrown. By default its value is -1 which indicates no timeout.

Examples:: test_eventserver.cpp.

Definition at line 283 of file eventserver.cpp.

References CMutex::enter(), CMutex::exit(), CTime::getTimeInTimeval(), search_event(), and CTime::set().

Here is the call graph for this function:

The documentation for this class was generated from the following files:

/builds/labrobotica/algorithms/iriutils/src/events/eventserver.h
/builds/labrobotica/algorithms/iriutils/src/events/eventserver.cpp
